OVERVIEW
CB500F
The 35kW learner licence-friendly CB500F street bike has a hard-edged stripped down muscular look. Features include a large fuel tank, LED lighting, spring preload adjustable front forks, lightweight exhaust and adjustable brake lever. Several vibrant paint options complement the aggressive angles. The styling shows off the machine’s mechanical forms; LED headlight and taillight are high quality finishing touches.
A large 16.7 litre fuel tank extends range. The riding experience is excellent due to adjustable spring preload in the front forks, smooth shifting gear box, wide tyres and sharp disc brakes.
FEATURES
TAKE A CLOSER LOOK
SPECIFICATIONS
YOUR BIKE IN DETAIL
Engine
| Engine Type | Liquid-cooled Parallel Twin |
| Displacement (CC) | 471cc |
| Bore and Stroke | 67mm x 66.8mm |
| Compression Ratio | 10.7:1 |
| Ignition | Full-transistorized type |
| Fuel System | PGM-FI, Electronic Fuel Injection |
Transmission
| Starter | Motor |
| Gearbox | 6-speed |
| Final Drive | Chain |
Wheels, Suspension & Brakes
| Suspension Front | Conventional Telescopic, 41 mm, Pre load adjustable |
| Suspension Rear | Pro-link mono with 9 stage Preload adjuster, steel square pipe swingarm |
| Brakes Front | Single Wavy Disk, 320mm, 2 POT Caliper |
| Brakes Rear | Single Wavy Disk, 240mm, 1 POT Caliper |
| Tyres Front | 120/70ZR – 17 M/C |
| Tyres Rear | 160/60ZR – 17 M/C |
| Rake Caster Angle | 25 °5' |
Dimensions & Weight
| Wheelbase | 1410mm |
| Seat Height | 790mm |
| GroundClearance | 160mm |
| Trail | 102mm |
| Kerb Weight | 190kg |
| Fuel Capacity | 15.7 litres |
| Dimensions | 2080mm(L) x 790mm(W) x 1060mm(H) |
